Sort Description:
This is a surface mount version of the popular XT60 power plug made by Amass. The connector uses. XT60EW-M connector (male plug) with mounting M2.5 fixing holes. It can conduct a current of 60 A and instantaneous current up to 100 A. due to its small dimensions it will be perfect as a battery connector or a power connector in RC models. It can be soldered on a cable or mounted on a circuit board. It has gold-plated contacts and a low resistance, which makes it characterized by good conductivity properties.
Features:
- Maximum current: 60 A (100 A instantaneous current)
- 12AWG, 14AWG AWG wires can soldered
- Gold-plated contacts
- For mounting on a cable or PCB
- Material: Nylon / PA
- Low Resistance of 0.8mΩ
Specifications:
Material: Heat Resistance Nylon
Insulation Material: UL94V-0
Contact Pins: Brass Gold Plated
Rated Voltage: DC 500V
Continuous Current: 60A
Instantaneous Current: 100A
Wiring Method: Welded
Operating Temperature: -20°C to 120°C
Size: 27x16x12mm
Weight: approx. 3g
Recommended Usage: 1000 times
What you Get:
1 x XT60EW-M Battery Connector -Male
