FlySky FS i6X Transmitter 2.4GHz 10CH, with FS-iA6B 6ch Receiver

FlySky FS i6X Transmitter 2.4GHz 10CH, with FS-iA6B 6ch Receiver
  • : In Stock
  • Model: ERST-FSi6X-RiA6B
Products Sold: 0
views 54
Ex Tax: 64.50€
FlySky FS i6X Transmiter 2.4GHz 10CH and FS-iA6B Receiver

Works in the frequency range of 2.405 to 2.475GHz.This band has been divided into 142 independent channels,each radio system uses 16 different channels and 160 different types of hopping algorithm.Silm design on transmitter for easy handling!
This radio system uses a high gain and high quality multi directional antenna,it covers the whole frequency band. Associated with a high sensitivity receiver,this radio system guarantees a jamming free long range radio transmission
Each transmitter has a unique ID, when binding with a receiver,the receiver saves that unique ID and can accepts only data from the unique transmitter.this avoids picking another transmitter signal and dramatically increase interference immunity and safety.
This radio system uses low power electronic components and sensitive receiver chip.The RF modulation uses intermittent signal thus reducing even more power consumption.
AFHDS2A system has the automatic identification function,which can switch automatically current mode between single-way communication mode and two-way communication mode according to the customer needs.
AFHDS2A has built-in multiple channel coding and error-correction,which improve the stability of the communication,reduce the error ratio and extend the reliable transmission distance.

Brand Name: FlySky
Item Name: FS-i6 transmitter
Channel: 10
Model Type: fixed wing/helicopter/glider
Channel resolution: 1024 steps
Low voltage warning: less than 4.2v
ANT length: 26 x 2mm (dual antenna)
Weight: 392g
Battery: 6v 1.5AA x 4 (not included)e
Size: 174 x 89 x 190mm
Color: black

RF specification:

RF Range: 2.405 - 2.475GHz
Bandwidth: 500khz
RF Power: less than 20dBm
RF mode: AFHDS 2A
Modulation type: GFSK
RX Sensibility: -105dBm

Receiver specification:

Channel: 6
Model type: fixed wing/helicopter/glider
RF receiver sensitivity: -105dBm
Modulation: GFSK System type: AFHDS2A/AFHDS
Channel resolution: 1024 steps
Bind port: yes Power port: yes( VCC)
iBus Interface: Yes
Compatible Receivers: FS-i4, FS-i6, FS-i10, FS-GT2E, FS-GT2
Power: 4V -6.5V DC
Weight: 6.4g
Antenna Length: 26mm
Dimensions: 47 x 26.2 x 15mm

What you Get:
1 x FS - i6X Transmitter 10CH AFHDS 2A
1 x FS - iA6B Receiver
1 x Manual
